> Surveillance Camera> Night Vision Car Rear View Camera> CMOS X-Small

5X CAMXS28PALMRR Wide Angle 150D Reverse View AutoFocus Camera XS 0.8in

5X CAMXS28PALMRR Wide Angle 150D Reverse View AutoFocus Camera XS 0.8in
click to see larger image
Name: 5X CAMXS28PALMRR Wide Angle 150D Reverse View AutoFocus Camera XS 0.8in
Your Price:
$176.00


Add product to your shopping cart

 Picture 1.  1.7mm Rear View Video COLOR AUTO-FOCUS WATERPROOF Camera with 150 degree (CC) viewing angle (please make sure you read our article on "Myth of 150 degree view" below) .

Offered here is an EXTRA SMALL (nickel size) FIVE (5) PIECE NEW EXCELLENT PROFESSIONAL QUALITY Brand New COLOR  Inside-Mount Wide View Angle Reverse Rear View NightVision* Camera; the lens has focal length of 1.7mm with 150 degree viewing angle (please make sure you read our article on "Myth of 150 degree view" below). This camera also come with AUTO-FOCUS capability and is WATERPROOF. It can also handle extreme weather conditions (-22F - 185F).



This camera has LUX rating of 0.5.  At night, it will automatically switch to night-vision mode without the need of ghostly infra red lights, thus making the camera very stealthy.  And with your tail lights, this camera will display almost anything within short distance of its sight.

We also sell exact size drill bits for this camera here...

Click these icons if you need the cable accessories

 Note: We design the camera to adapt to constantly changing voltage levels (within normal range +/- 10%) produced by vehicles' battery and alternator. However, during start up, some vehicles have very high momentary voltage which may cause overload and damage to the camera. To avoid such situation, we advice you to seek professional vehicle audio/video equipment installers.

Specification:
Number of Pixels 720 X 576 (PAL)

for our USA customer, as long as you have a multi system monitor

, you can take advantage of the 150degree provided by this PAL camera.
TV System PAL
Sync System Internal
Image Sensor / Resolution:  OV7910  1/4in CMOS
Minimum Illumination 0.5 LUX - Night Vision* aided with Reverse light
S/N Ratio:  More than 48dB
Scan Frequency 60Hz
Power Source:  DC 12V/110mA (Tolerance: +/- 10%)
Power consumption 50mA  Max 110mA
Lens:  1.7mm
View Angle: 150 degree CC or 120 degree SS - see "Myth of 150 degree view" below
Dimension: approximately 27.5mm L x 17.5mm Dia (Front Plate Dia is 20.6mm or 0.8125in)
Picture Delay Full Motion Real Time Color Video without delay
view Displays a reversed camera image on the monitor to duplicate the normal view seen in a rear-view mirror
Water proof Yes
Operating Temperature -22F - 185F (-30C to 85C) / RH 95% Max
Storage Temperature -22F - 185F (-30C to 85C) / RH 95% Max
Casing Hard Metal Casing
Video Output 1.0V Peak to Peak
Shutter Dual electronic rolling shutter (DERS)
Advanced Image Processing Auto exposure, AWB, ABR, auto flicker reduction, auto color saturation, auto defect identification and correction capabilities built into camera circuit
Mount Mounted Inside will fit into most vehicle key holes - no other installation needed

Q&A:

NightVision* Question from customer: this camera does not come with Infrared LED light, so how can it see objects in the dark

 Answer: The sensor is hyper sensitive and need only the reverse light to pickup and display objects when you put your vehicle in reverse gear.

Myth of 150 degree view

Viewing angle can refer to either of these angles shown in the diagram below.

1. Side to Side Viewing Angle (Let's call it SS Angle) 2. Corner to Corner Viewing Angle (Let's call it CC Angle)

For 1.7mm lens, the CC angle is approximately 150 degree, but the SS angle is approximately 120 degree.
