Offered here is ONE (1) new aftermarket marine remote GPS antenna and 1 meter long cable. This antenna is rated at 37dB with BNC MALE JACK connector . this antenna is capable of supporting a cable length with a maximum of 30 meter or 100 feet (WOW!!!) Even at less than 10m, this antenna will be more sensitive than the 25dB that we also sell (click on any icons below / see table at bottom page)
For your info, the longer the cable is, the more dB loss you will experience, which is why you need this antenna if your antenna cable is going to be over 10m long.
We supply a 1 meter 3.3 feet cable because it will be too expensive for me to ship 30 meter long cable to you. You can get the 30m heavy cable with a lower price at your local GPS shop.
Photo #1: What you see in photo #1 above is what you get (ruler not included) Listing is for an active antenna only, does not come with internal GPS receiver. This antenna is rated at 37dB with BNC MALE JACK connector . It is capable of supporting cable length with a maximum of 30 meter or 100 feet (WOW!!!) We supply a 1 meter 3.3 feet cable because it will be too expensive for me to ship 30 meter long cable to you. You can get the 30m heavy cable at a lower price at your local GPS shop.
It is compatible with:
Garmin StreetPilot GPS, StreetPilot GPS ColorMap, StreetPilot III GPS, StreetPilot III Deluxe, GPS II, GPS II+, GPS III, GPS III+, GPS III Pilot, GPS V, GPS 45, GPS 45XL, GPS 48, GPS 50, GPS 65, GPS 75, GPS 89, GPS 90, GPS 92, GPS 95XL, GPS 100, GPS 100STD, GPS 120, GPS 120XL, GPS 125 Sounder, GPS 128, GPSMAP 130, GPS 135, GPSMAP 135 Sounder, GPSMAP 152, GPSMAP 162, GPSMAP 168 Sounder, GPSCOM 170, GPSMAP 172C, GPSMAP 176, GPSMAP 176C, GPSMAP 178C Sounder, GPSMAP 180, GPSMAP 182, GPSMAP 182C, GPSMAP 185 Sounder, GPSMAP 188 Sounder, GPSMAP 188C Sounder, GPSMAP 196, GPSMAP 200, GPS 205, GPSMAP 210, GPSMAP 215, GPSMAP 220, GPSMAP 225, GPSMAP 230, GPSMAP 232, GPSMAP 235 Sounder, GPSMAP 238 Sounder, GPSMAP 276C, GPSMAP 295, GPSMAP 296, NavTalk Pilot.
The amplified Marine GPS antenna consist of randome and lower housing that is built with highly durable polycarbonate, with a rubber o-ring for waterproofing, and a hermetically molded cable for waterproof and strain relief. Also comes with 1 meter or 3.3 ft. of heavy duty cable. Our antennas are manufactured with strong polycarbonate housing with die-cast steel base plate. We use the the toughest UL-certified materials at ISO 9000/9001/9002 certified factories.
Antenna comes with a built-in pole mount of a standard 1" marine thread. Comes with high signal gain (37dB of signal gain) and durable/waterproof housing, making it the most popular and highly demanded marine GPS antenna! The "dB" level determine the maximum length of your cable.
Size Diameter=96mm ¡Á height=126mm
Connector BNC Male
Mounting screw £¨G3/4£©connect¡¡
Built-in pole mount -- standard 1" marine thread.
Connect cable¡¡ SYV50-3 with 1m length (you can extend the cable up to a maximum of 30 meter! WOW!!!)
Weight (including dome & 33 feet cable & connector) : 553gram
Antenna gain ¡Ý3.5dBic at 10C
Amplifier gain ¡Ý37dB typically.
Interference rejection ¡Ý25dB for ¡À100MHz
Noise figure ¡Ü1.5dBi typically.
Supply Voltage 3V/5V DC
Polarization right- hand circular
Reflection loss -14dB(or VSWR¡Ü1.5dB)
Relative Humidity 100%
Storage Temperature -50C to +90C
Operating Temperature -45C to +85C
Car / Marine / Aviation Navigation
GPS Antenna for Aircraft or Marine Avionics
External Antenna for your onboard GPS
