Picture 1. Wide Angle Security Door Viewer Camera
to monitor who is knocking on your door. No more surprises. Since this is a camera, those outside cannot use a reverse door viewer to see who is inside! The camera comes with a video output and power (DC 12V) input.
What you see in picture 1 is what you get. Ruler (not included) is for measurement purpose only. This viewer will fit doors having a maximum thickness of
90mm, minimum thickness of 16mm.
Click these
icons if you need the cable accessories
|
Picture 2: The yellow female RCA plug connects to any TV/monitor that has an RCA input signal line. Every TV that will connect to a VCR/DVD player is guaranteed to work with our camera. the red power cable (plug) should be connected to a 12 V power supply
which we also sell
 . If you don't have the connecting head that fits our plug, you can cut the red plug from our camera and connect the exposed line directly to a DC 12V power supply. Please make sure that the middle line is connected to positive +12V, and the other line goes to ground.
Click these
icons if you need the cable accessories
|
DESCRIPTION
Offered here is ONE (1)NEW EXCELLENT QUALITY Brand New Wide Angle Security Door Viewer Camera with the following spec:
TV System: PAL
Image Sensor: 1/3" Sony CCD
Horizontal Viewing Angle:
TRUE SUPER WIDE 136 Degree
(read
Myth of 170 degree view
below)
Voltage: DC 12V
Output: Video jack
Array Size (PAL): 480*400 pixels
Auto Electronic Exposure: 1/50 - 1/6000
Min. Illumination (3000k): 0.2 LUX (WOW!) @ f1.4
Focus: Manually Adjustable
Exposure: Automatic
Current Consumption: Less than 120mA
Iris: Automatic
Viewing Distance: 50 mm to infinity
Full Motion Real Time
Color Video without delay
Scan Frequency: 60Hz
Operating temperature: -10 to +50 Celcius
Water resistant: Yes
Picture type:
COLOR
This viewer will fit doors having a maximum thickness of
90mm, minimum thickness of 16mm.
Diameter is 0.997 inch or 25.32mm
View who is outside from the comfort of your sofa. Provision locking device to prevent unscrewing from outside. High-quality glass optical lens. EASY INSTALLATION similar to any other door viewer! You can connect the camera to an alarm system if you want the alarm to sound whenever someone is at the door.
Installation
Only takes about 3 minutes to install entire system
Connect camera to any standard television or VCR with the RCA cable (cable not included)
Plug the DC
12V adaptor (not included) into the power jack of the camera.
If you don't have a DC12V adapter with the plug that fits our camera's, simply
cut the power cable of the adapter and our camera, and manually connect the +ve
and -ve cable to our camera's cable make sure you unplug the adapter from your
wall socket when you do this).
Adjust camera to its best position
set TV to AV mode
That's it! You will get the vivid video picture!
Operating Voltage: AC-DC +12V Power Adapter
AC-DC Power Adapters Operating Duration: 24-hour non-stop
|
Myth of 170 degree view
Question from
customer:
Your competitor sells
similar camera with 1.7mm lens and stated that their camera viewing
angle is 170 degree. How come your 1.7mm camera has a much smaller
viewing angle of 136 degree?
Answer:
This is one of those misinformation which our competitor
never truly discloses to their customer. Here is the fact.
Viewing angle can refer to either of
these angles shown in the diagram below.
 |
 |
| 1. Side to Side Viewing Angle
(Let's call it SS Angle) |
2. Corner to Corner Viewing
Angle (Let's call it CC Angle) |
Our competitor may be referring to the
CC angle and not the SS angle. Our 136 degree view refers to SS
angle.
And not all 1.7mm camera can achieve 136
degree. We have seen cameras with 1.7mm lens that has only 90
degree view. How could that happen? It happens because the
camera uses cheap CCD chip that cannot handle such a wide angle view.
So watch what you are buying.
So the next time when a seller tells
you that their 1.7mm camera can achieve a viewing angle of 170 degree,
make sure you know what he is talking about.
|
|
