Picture 1: What you see
in picture 1 above is what you get including software driver.
|
DESCRIPTION
Offered
here is THREE (3)
piece of BRAND NEW HI-N TCP/IP to RS485 or RS422 or RS232 converter box. With
this interface box, you can communicate with your RS-485 or RS-422 or RS-232
devices via your network LAN router. The software driver provides the interface
for your application to communicate with your device seamlessly. The software driver supports Windows
XP/2000/98.
This
converter :
-
RS232 end connect to your device via the
RS232cable.
-
RS485/422 end connects to your
RS485/422 device.
-
Internal CPU: 16 bit, 100 MHz
-
Internal Memory: 256 KB ROM + 768 KB SDRAM
-
Works with a variety of devices including:
Modems, Smart card readers, Terminals, POS (point of sale) devices,
Industrial control devices, RS232 peripheral upgrades.
-
10/100M full duplex
-
COM port speed: 1200bps to 230.4 kbps
-
Supported Protocols: SOCKS5, HTTP, ARP, IP,
ICMP, UDP, TCP
-
Built in surge protector up to 3500V
-
Connection Ports: RJ45 (LAN port), RS232,
RS485, RS422
-
Flow control software: Xon/Xoff + Hardware RTS/CTS
DTR/DSR
-
Signal: RS-232:TxD,RxD,RTS,CTS,DTR,DSR,DCD,GND
-
Signal: RS-422:TXD+/-,RXD+/-,(RTS+/-, CTS+/-
selectable), GND
-
Signal: RS-485:Data+/-,GND
-
Software driver supports OS - Windows
98/98SE/ME/2000/XP.
Package Includes:
1. TCP/IP-RS485/422/232 converter box.
2. Power adapter or power supply.
3. RS232 cable.
4. Software driver for Windows 98/98SE/ME/2000/XP.
|
Specifications: |
|
|
Communication port |
TCP/IP - RS485/422/232 |
|
Data transfer
rates: |
1200bps to 230.4
kbps |
|
Compatibility |
Windows
98/98SE/ME/2000/XP |
|
Dimensions |
3 x 2.5 x 1 inch |
|
CPU |
16 bit, 100 MHz |
|
Memory |
256 KB ROM + 768 KB
SDRAM |
|
Communication |
10/100M full duplex |
|
Protocols |
SOCKS5, HTTP, ARP,
IP, ICMP, UDP, TCP |
|
