1X CAMSM28NTSCMRR Small Backup Car MIRROR View NTSC IR Camera

1X CAMSM28NTSCMRR Small Backup Car MIRROR View NTSC IR Camera
click to see larger image
Name: 1X CAMSM28NTSCMRR Small Backup Car MIRROR View NTSC IR Camera
Your Price:
$37.00


Add product to your shopping cart





 Picture 1.  2.8mm Rear View Video COLOR Camera with 105 degree viewing angle (please make sure you read our article on "Myth of 120 degree view" below) and reverse view.

What you see in picture 1 is what you get











DESCRIPTION

Offered here is a ONE (1) PIECE NEW EXCELLENT PROFESSIONAL QUALITY Brand New COLOR  Inside-Mount Wide View Angle Reverse Rear View Camera; the lens has focal length of 2.8mm with 105 degree viewing angle (please make sure you read our article on "Myth of 120 degree view" below).



Comes with waterproof O-ring!!!

New Improved Version with super mini size!!!

VS

Old model:





This camera is compatible with major TFT screens out there in the market

Camera comes with RCA video output socket (yellow), and 12V power input socket (red)









For the red power cable, the middle pin is positive (connects to +12V of your power supply), and the outer ring is neutral / ground.

The yellow female RCA plug connects to any TV/monitor that has an RCA input signal line.  Every TV that will connect to a VCR/DVD player is guaranteed to work with our camera.  the red power cable (plug) should be connected to a 12 V power supply, which is the voltage all standard van/car battery provides.  If you don?t have the connecting head that fits our plug, you can cut the red plug from our camera and connect the exposed line directly to your car battery?s power supply.  Make sure you have the power polarity connected correctly.

For the red power cable, the middle pin is positive (connects to +12V of your power supply), and the outer ring is neutral / ground.

Click these icons if you need the cable accessories

 Note: We design the camera to adapt to constantly changing voltage levels (within normal range +/- 10%) produced by vehicles' battery and alternator. However, during start up, some vehicles have very high momentary voltage which may cause overload and damage to the camera. To avoid such situation, we advice you to seek professional vehicle audio/video equipment installers.







Specification:
Number of Pixels 510 X 492 (NTSC)

for our USA customer, as long as you have a multi system monitor, you can take advantage of the 105degree provided by this NTSC camera.

TV System NTSC
Sync System Internal
Image Sensor / Resolution:  OV7910  1/3 CMOS
Minimum Illumination 0 LUX - Infrared Night Vision
S/N Ratio:  More than 48dB
Scan Frequency 60Hz
Power Source:  DC 12V/110mA (Tolerance: +/- 10%)
Power consumption 50mA  Max 300mA with IR on
Lens:  2.8mm / F2.0
View Angle: 105? (105 degree)
Screw Thread diameter (Dia) 23mm
Dimension: approximately 41mm L x 29mm Dia
Picture Delay Full Motion Real Time Color Video without delay
view Displays a reversed camera image on the monitor to duplicate the normal view seen in a rear-view mirror
Water resistant Yes
Operating Temperature 14?F - 115?F (-10?C to 46?C) / RH 95% Max
Storage Temperature -22?F - 140?F (-30?C to 60?C) / RH 95% Max
Casing Hard Metal Casing
Mount Mounted Inside will fit into most vehicle key holes - no other installation needed





Q&A:

Question from customer: will the night vision cameras work during the day, what kind of quality picture can I get, how will the night vision work when a car comes up behind me with its headlights on.

 Answer: The lens comes with a light sensor.  During daylight or cloudy weather, when everything can still be seen with naked eyes, the camera will stay on daylight mode such that it will work similar to any other camera without additional artificial light source. During night time or when inside very dark garage, the light sensor will detect the low ambient light and will automatically turn on the infra red diodes; the camera will then display what normal eyes cannot see under such condition without additional light source.  In other words, regardless of the light condition, you will see things as if it is daytime regardless of day or night or low light or cloudy conditions (remember, at night, the object must be within the distance we stated in the table of picture 1 above).





Myth of 120 degree view

Question from customer: Your competitor sells similar camera with 2.8mm lens and stated that their camera viewing angle is 120 degree.  How come your 2.8mm camera has a much lower viewing angle?

 Answer:  click this link to view the answer in PDF format
