What you see above is what you get.
Offered here is FIVE
(5) sets of new good quality
13.56Mhz USB RFID Writer/Reader for Mifare ISO14443A MF1 S50 & S70
Power is obtained from USB cable. External power adaptor not needed. The
card writer writes information into the card without anyu physical contact.
Simply place the card within 5 cm above the writer and the data will be written
onto the IC chip inside the card.
Specifications:
Mifare MF1 S50 Features:
* Unique serial number
* 1K byte EEprom memory , orgamized in 16 sector with 4 blocks of 16 bytes each
(one block consists of 16 byte)
* User definable access conditions & password for each memory block
* 10 years Data retention
* 100,000 cycle write endurance
Data format: Baud Rate: 9600, N, 8, 1
STX (02 HEX) / DATA / CR / LF / BCC / ETX (03 HEX)
* STX' (02 HEX ) – start character
* Data – ASCII data output
* CR – enter & Line feed character
* BCC – Data Xor CR & LF
* ETX (03 HEX) – end character
Feature:
* Built-in transceiver antenna;
* Built-in bi-color LED and buzzer
* Operation frequency : 13.56Mhz
* Less than 100ms decoding time
* Maximum effective distance up to 5cm (ISO card)
* Power is obtained from USB cable. External power adaptor not needed.
* Support Mifare MF1 S50 & S70 ISO/IEC 14443A RF interface
* Size : (115x82x25)mm
* USB interface
* Zero Contact Read Write operation
Software include:
* Demo program show how to read & write the data into the tag
* demo program's source code (built by Delphi) - speed up software development
time
* API implementation as a DLL for Visual C++ under Windows XP
* communication protocol for non-PC application
* data sheet, user manual
