Picture 1:
What you see above in picture 1 is what you get, you get
TWENTY (20) PIECES of
 .
Key Features:
A. GERMAN design conversion kit
B. Strong and rapid startup;
C. Super brightness, reaches 3600 lumens;
D. Highly stable illumination.
E. Excellent anti-interfering
function, do not interfere the other electronics equipments on the
car
F. Works with any Xenon HID car lamp
|
This ballast fits any aftermarket HID
conversion Kits.
It will fit directly into your existing Xenon headlights. Xenon gas inside
the special sealed bulb of every HID Pro Conversion Kit requires very high
voltage to light up. This ballast will do the job by generating the required
25,000V for 3 msec to ignite the Xenon gas inside the bulb. The ballast then
controls and regulates the electrical discharge between the two electrodes
inside the bulb at the required voltage.
|
Picture 2: Cable |
Specifications:
1)Input voltage rage: DC 8-18V
2)Rated voltage:13.5V
3)Max.start voltage:23KV
4)Input current:3.1A+/- 5%
5)Output power:35W+/-2W
6)Luminosity:3600lumens
7)Working temperature:-40~ 105?C
8)Color temperature:4300K-12000K
or above
9)Life-span:3000 hours
10)Startup time: Can reach 40%
of the standard brightness within 1 second; can reach 80% of the standard
brightness within 2.5 seconds.
11)Auto Cut-off: Once there is a
short circuit or open circuit, the ballast will stop working automatically.
12)Protection voltage: When the
voltage exceed 19V, the ballast will stop working automatically, and make
the output power below 45W, to protect the ballast and bulb from damage.
When the voltage is 8V, the ballast still can work normally, but when the
voltage is below 7V, the ballast will stop working to protect the ballast
from damage.
13) Reverse polarity protection:
The ballast will stop working automatically when a reverse polarity happens.
14) Also use with HID lamp of type D2S, D2R
15)Radiation:
Relative value:≤-70DB
Absolute Value:≤20microwatt
For Standard Wireless
Interference /
Relative value:≤-90DB
Absolute Value:
≤
5microwatt For Our Product.
|
