Offered here is 20 PIECES new aftermarket Remote Amplified Antenna for All GPS with right angle SMB MALE JACK connector for easy maneuvering .
Compatible with the following GPS units:
Magellan RoadMate 300, RoadMate 500, Magellan RoadMate 700 & Magellan Meridian Color and any other GPS receivers with SMB Plug/Male Antenna connector
WARNING:
SOME BUYERS CLAIM THEIR ROADMATE 300/500/700 USES SMB-MALE PLUG INSTEAD OF SMB-FEMALE PLUG. BEFORE MAKING YOUR BID/PURCHASE, PLEASE MAKE SURE YOU KNOW WHICH PLUG YOU REQUIRE. PLEASE CLICK ON THIS ICON IF YOU WANT AN SMB-MALE OR THIS ICON IF YOU WANT AN SMB-FEMALE.
Specifications:
- Low power consumption: 6 to 11 mA (max)
- Magnetic mount (magnet can be removed)
- High signal gain: 28 dB Gain (if you need a repeater to boost the GPS signal, then buy this
 by clicking on this icon  )
- Power Protection Circuit
- Power Input Sensor: Reverse polarity short circuit shutdown
- Over-Current Sensor: Thermal over-current shutdown
- Low noise: noise figure less than 1.8dB at f0
- Output Impedance: 50 ohms
- Waterproof
- Weight: 71gram
- Power Input: 2.5V DC to 12V DC input
- Super strong polycarbonate radome
- Physical dimensions: 1.5”(W) x 1.76”(L) x .5”(H)
- Over 10 feet long double shielded coax cable
|
