1x CAMXXSHAEMRRPL Waterproof Color BackUp Rear View IR Reverse Camera NEW

1x CAMXXSHAEMRRPL Waterproof Color BackUp Rear View IR Reverse Camera NEW
click to see larger image
Name: 1x CAMXXSHAEMRRPL Waterproof Color BackUp Rear View IR Reverse Camera NEW
Your Price:
$38.00


Add product to your shopping cart





 Picture 1.  Waterproof Rear View Video COLOR Camera with 90 degree viewing angle (please make sure you read our article on "Myth of 120 degree view" below)

What you see in picture 1 is what you get



(Click on this icon if you prefer a normal view (non-reverse) camera .

Camera comes with RCA video output socket (yellow), and 12V power input cables





Offered here is a ONE (1) PIECE NEW WATER-PROOF Brand New COLOR  Inside-Mount Backup View Angle Reverse Rear View Camera;



The entire camera can be submerged in water and still function perfectly.



the lens has focal length of 1.7mm with 90 degree viewing angle.  (please make sure you read our article on "Myth of 120 degree view" below)

(Click on this icon if you prefer a 6.0mm video camera with 53 degree viewing angle or this with 15 meter night vision ).
Comes with reverse camera viewing system which displays a reversed camera image on the monitor to duplicate the normal view seen in a rear-view mirror.



Specification:
Number of Pixels PAL: 648(H) * 488(V)
Sync System Internal
Image Sensor / Resolution:  more than 480 TV lines
Minimum Illumination 0.1 LUX
S/N Ratio:  More than 48dB
Scan Frequency 60Hz
Power Source:  DC 12V/ 110mA (Tolerance: +/- 10%)
Lens:  1.7mm
View Angle: 90 degree
Dimension: approximately 0.866 L x 0.75 inch Dia
Picture Delay? Full Motion Real Time Color Video without delay
view Displays a reversed camera image on the monitor to duplicate the normal view seen in a rear-view mirror
Waterproof Yes
Operating Temperature 14F - 115F (-10C to 46C) / RH 95% Max
Storage Temperature -22F - 140F (-30C to 60C) / RH 95% Max
TV System PAL
Casing Hard Metal Casing
Mount Mounted inside or outside of vehicle, camera is water proof, won't fog.





Q&A:

Question from customer: will the night vision cameras work during the day, what kind of quality picture can I get, how will the night vision work when a car comes up behind me with its headlights on.

 Answer: The lens comes with a light sensor.  During daylight or cloudy weather, when everything can still be seen with naked eyes, the camera will stay on daylight mode such that it will work similar to any other camera without additional artificial light source. During night time ??? or when inside very dark garage, the light sensor will detect the low ambient light and will automatically turn on the infra red diodes; the camera will then display what normal eyes cannot see under such condition without additional light source.  In other words, regardless of the light condition, you will see things as if it is daytime regardless of day or night or low light or cloudy conditions (remember, at night, the object must be within the distance we stated in the table of picture 1 above).



Myth of 120 degree view

Question from customer: Your competitor sells similar camera with 2.8mm lens and stated that their camera viewing angle is 120 degree.  How come your 2.8mm camera has a much lower viewing angle?

 Answer: This is one of those misinformation which our competitor never truly discloses to their customer.  Here is the fact.

Viewing angle can refer to either of these angles shown in the diagram below.

1. Side to Side Viewing Angle (Let's call it SS Angle) 2. Corner to Corner Viewing Angle (Let's call it CC Angle)

For 2.8mm lens,

if it is PAL format, the CC angle is approximately 120 degree, but the SS angle is approximately 110 degree.  If you want to buy this PAL camera, simply click on this icon: If you don't have a multi system monitor (capable of displaying both PAL and NTSC), then buy from us by clicking on this icon:

if it is NTSC format, the CC angle is approximately 105 degree, but the SS angle is approximately 95 degree.  If you want to buy this NTSC camera, simply click on this icon:

So the next time when a seller tells you that their 2.8mm camera can achieve a viewing angle of 120 degree, make sure you know what he is talking about.
